SUPPORTED VEHICLE DETAILS

Toyota

Make

Corolla

Model

2020

Year
System Prox: Type 8; Keyed: By Vehicle > Corolla > Non Proximity > 2023; Prox: By Vehicle > Corolla > Proximity > 2019-
Add-A-Key Yes
All-Keys-Lost Yes
PIN Read
Programs Remotes No
Resync Available No
Notes:

2018+ Toyota/Lexus MAY NEED a rolling code conversion. Not ALL models 18+, but quite a few, and the newer the model, the more likely you'll need to convert. You can use a 3rd party conversion, https://techinfo.toyota.com/ with NASTF directly, or use the ANYTOYO and Cert unit cable (prox only). Anytoyo helps with bypassing rolling code via OBD up to 2021, after that you MAY need (model dependent) to tie directly into Cert unit using a cable such as the ADC-2021.

Compatible Parts List

Toyota Camry/Corolla 2018-2025 4-Button Remote
Toyota Corolla 2019-2021 4-Button Smart Key
Toyota Corolla Hatchback 2019-2022 3-Button Smart Key
Tex 4D-74 (Toyota H-Chip) Tag MASTER Transponder Chip (Toyota)
CR1620 3-Volt Lithium Batteries 5-Pack
CR2032 3-Volt Lithium Batteries 5-Pack
Toyota 2012-2021 Smart Key Emergency Key
MFK-076 Refill Blades 10-Pack Toyota TR47
MFK-HEAD-079 Heads 5-Pack Toyota (Gray) Style
Toyota TOY44H Transponder Key
